Century ARB2024M Belt Drive Fan and Blower Motor
| Phase | Single Phase |
|---|---|
| Voltage | 115 |
| Frame | 56Z |
| Enclosure | TENV |
| Brand | Century |
| Electrical Type | Split Phase |
| Rotation | Reversible |
| Amps | 4.3 |
| Horsepower | 1/4 |
| Motor_Diameter | 6.5 |
| Product_Type | Belt Drive Fan and Blower Motor |
| Shaft_Type | Single |
| mpn | ARB2024M |
| Product Type | Belt Drive Fan and Blower Motor |
| Diameter | 6.5 |
| Overload | Auto |
| Material | Rolled Steel |
Please fill in the fields below with the shipping destination details in order to calculate the shipping cost.
$397.72
In stock
Replacement motor specifications may differ from OEM. All replacement units are based on manufacture cross reference. Please give us a call if you have any questions you can also refer to our FAQ page located here (Frequently Asked Questions)
Local Pickup & Courier Delivery
(Refer to the Shipping & Delivery Section under the product description for more information)
Warehouse Locations: CA, CT, GA, MI, IL, TX, MD, MO, SC, IN, WA, PA
Phone: 517-543-4080
Century ARB2024M Belt Drive Fan and Blower Motor
The Century ARB2024M Belt Drive Fan and Blower Motor is a robust electrical split phase motor designed for various applications, including centrifugal pumps, blowers, and fans. This motor operates on a single phase with a voltage of 115, featuring an auto overload protector and a durable rolled steel enclosure.
Specifications:
- Type: Split phase
- Phase: Single
- Voltage: 115V
- Overload Protector: Auto
- Frame: 56Z
- Enclosure: Totally Enclosed Air Over (TEAO)
- Material: Rolled steel
- Horsepower: 1/4 HP
- Rotation: Reversible
- RPM: 1725
- Number of Speeds: 1
- Frequency: 60 Hz
- Load Amps: 4.3
- Service Factor: 1.00
- Bearing Type: Sleeve bearings
- Warranty: 1-year manufacturer warranty
Key Features:
- Class B insulation
- Continuous duty operation
- Energy efficient
- Reversible design
- Quick connect terminals for easy installation and rotation change
This motor is designed for reliable performance and is suitable for a variety of applications, ensuring efficiency and durability in operation.
| Weight | 18.7 lbs |
|---|---|
| Phase | Single Phase |
| Voltage | 115 |
| Enclosure | TENV |
| Frame | 56Z |
| Enclosure | TENV |
| Brand | Century |
| Motor_diameter | |
| Warehouse Locations | CT, MI, TX |
| Electrical Type | Split Phase |
| Rotation | Reversible |
| Amps | 4.3 |
| Horsepower | 1/4 |
| Motor_Diameter | 6.5 |
| Product_Type | Belt Drive Fan and Blower Motor |
| Shaft_Type | Single |
| mpn | ARB2024M |
| Product Type | Belt Drive Fan and Blower Motor |
| Diameter | 6.5 |
| Speeds | 1 |
| Overload | Auto |
| Material | Rolled Steel |
