US-Nidec S10P2A General Purpose Motor
| Voltage | 208/230/460 |
|---|---|
| Speeds | 1 |
| Brand | US-Nidec |
| Rotation | Reversible |
| Shaft_Diameter | 1.375 |
| Shaft_Type | Single |
| Horsepower | 10 HP |
| Amps | 26.6-24/12 |
| mpn | S10P2A |
| Phase | Three Phase |
| Product_Type | General Purpose Motor |
| Frame | 215T |
| Enclosure | TEFC |
| Overload | No |
| Material | Rolled Steel |
| Bearings | Ball / Ball |
Please fill in the fields below with the shipping destination details in order to calculate the shipping cost.
$1,242.04
In stock
Replacement motor specifications may differ from OEM. All replacement units are based on manufacture cross reference. Please give us a call if you have any questions you can also refer to our FAQ page located here (Frequently Asked Questions)
Local Pickup & Courier Delivery
(Refer to the Shipping & Delivery Section under the product description for more information)
Warehouse Locations: CA, CT, GA, MI, IL, TX, MD, MO, SC, IN, WA, PA
Phone: 517-543-4080
US-Nidec S10P2A General Purpose Motor
The US-Nidec S10P2A General Purpose Motor is a robust and versatile 10hp motor designed for a variety of applications. Operating at 1800rpm, this motor is built with a NEMA 215T frame size and is ideal for general purpose use.
Specifications:
- Horsepower: 10hp
- Speed: 1800rpm
- Frame Size: NEMA 215T
- Amperage: 26.6-24.0/12.0 amps
- Voltage: 208-230/460 volts
- Frequency: 60Hz
- Shaft Diameter: 1 3/8″ x 3 1/2″
- Service Factor: 1.15
- Protection: Overload protection
- Cooling Type: Totally Enclosed Fan Cooled (TEFC)
- Mounting: Rigid base mount
- Bearing Type: Ball bearings
- Insulation Class: Class F
This motor is reversible, making it suitable for a wide range of applications. It is backed by a 1-year manufacturer warranty for added peace of mind.
